Marin San Quentin 24

£999.00

Designed with the input of freeride legend Matt Jones, the San Quentin takes the DNA of our dirt-jumping Alcatraz and mutates it into a go-further and faster all-round, hardcore hardtail.

The San Quentin 24” will feel just like a ‘grown up’ mountain bike to your little ripper, built with a stout Series 2 aluminum frame, 24” wheels, and for 2025/26, a new Manitou J Unit 100mm air suspension fork meaning more adjustability for lighter shredders.

Further updates include a one piece seatpost and saddle to allow for a lower standover and ride height, 1 x 9-speed Shimano Cues drivetrain, tubeless compatible tyres kid’s specific hydraulic disc brakes.

Designed with the input of freeride legend Matt Jones, the San Quentin takes the DNA of our dirt-jumping Alcatraz and mutates it into a go-further and faster all-round, hardcore hardtail.

The San Quentin 24” will feel just like a ‘grown up’ mountain bike to your little ripper, built with a stout Series 2 aluminum frame, 24” wheels, and for 2025/26, a new Manitou J Unit 100mm air suspension fork meaning more adjustability for lighter shredders.

Further updates include a one piece seatpost and saddle to allow for a lower standover and ride height, 1 x 9-speed Shimano Cues drivetrain, tubeless compatible tyres kid’s specific hydraulic disc brakes.

Specifications

Frame

Series 2 6061 Aluminum, 24” Wheels, Disc Specific, 30.9 Post and Dropper Compatible

Front Suspension

Manitou Junit Sport, 24", 100mm Travel, Air Sprung, Adjustable Rebound, Tapered Steerer, 15x110mm Axle

Rim

Marin, Double Wall Alloy, 26mm Internal, Tubeless Compatible

Hub Rear

Forged Aluminum, 32H, Disc Specific

Hub Front

Forged Aluminum, 32H, Disc Specific

Spokes

14g Stainless Steel

Tires

Delium Versatile, 24”x2.4”, Light Construction, Wire Bead, Tubeless Compatible

Derailleur Rear

Shimano CUES, RD-U4000, 9-speed

Shift Lever

Shimano CUES, SL-U4000, 9-speed

Crankset

Forged Alloy, Narrow Wide 30T, 140mm

Bottom Bracket

Sealed Cartridge Bearings, Square Taper

Chain

KMC X-Glide

Cassette

Shimano CUES, CS-LG3000, 9-Speed, 11-46T

Brakes Front

Shimano MT200, Hydraulic, 160mm Rotor

Brakes Rear

Shimano MT200, Hydraulic, 160mm Rotor

Brake Levers

Shimano Hydraulic

Handlebar

Marin Riser, 31.8mm Clamp, 30mm Rise, 580mm Width, 19mm OD Grip Section

Stem

Marin Alloy, 40mm

Grips

Marin MTB, Small Diameter

Headset

FSA No. 57E

Seatpost

Integrated With Saddle

Saddle

Marin One-Piece Saddle/Post Combo, 27.2mm Alloy Post

Pedals

Kids Specific Nylon Pedal
